UV LEDs

Lumileds sets the UV LED standard with the industry’s smallest high-power UV LED emitter.

LUXEON IR 2720 Line

LUXEON IR 2720 is a line of high power infrared emitters in a reliable package design, affirming long lifetime and robustness in many types of application conditions. The LUXEON IR 2720 Line uses an industry standard footprint for ease of integration and upgrades of existing system designs.

  • Available in 850nm and 940nm wavelengths to provide optimized performance for each type of application
  • Radiant Power: 1300 mW (850nm) and 1250 mW (940nm) for a greater system performance
  • 2.75mm x 2.00mm package with a 2 pad configuration that is compatible with the industry standard footprint to enable a direct upgrade in existing designs

LUXEON IR Compact Line

The LUXEON IR Compact Line is a product line of high power infrared emitters specifically designed for high efficiency as required in a small spaces. Their compact and well-defined light source geometry allows them to be easily coupled into secondary optics for tight beam control. LUXEON IR Compact Line is designed with innovative LUXEON technology to provide industry-leading performance. Through best-in-class thermal conductivity, LUXEON IR Compact Line has excellent performance at actual operating conditions.

  • Available in 850nm and 940nm wavelengths to provide optimized performance for each type of application
  • Radiant Power: 1050mW (850nm) and 1150mW (940nm) for a greater system performance
  • Compact package of 1.9mm x 1.37mm with a 2-pad configuration provides the highest power density in the industry for a new level of miniaturization
  • Ultra-low Rth of 2.8°C/W, solves thermal challenges and supports space saving designs

LUXEON IR Domed Line

The LUXEON IR Domed Line for Automotive is a product line of high power infrared emitters with Automotive qualification tailored to application needs by offering a variety of products at multiple infrared wavelengths and optical radiation patterns. LUXEON IR Domed Line is designed with innovative LUXEON technology to provide industry-leading performance. Through best-in-class thermal conductivity, LUXEON IR Domed Line has excellent performance at actual operating conditions. The LUXEON IR Domed Line uses an industry standard footprint for ease of integration and upgrading existing system designs.

  • Available in 850nm and 940nm wavelengths to provide optimized performance for each type of application
  • Radiant Power of 1350mW (850nm) and 1450mW (940nm) for greater system performance
  • Four emission patterns of 50°, 60°, 90° and 150° to address diverse application needs, high punch, long range and high uniformity
  • 3.7mm x 3.7mm package with 3 pad configuration is compatible with the industry standard footprint, enabling a direct upgrade in existing designs
  • Ultra-low Rth of 2-3.1°C/W, the industry’s best thermal conductivity, solves thermal challenges and supports space saving designs

LUXEON IR ONYX

The LUXEON IR ONYX emitter features a continuous broadband infrared (IR) emission from 650 to 1100nm with superior light output characteristics. The product comes in an industry standard 2720 package and footprint for easy integration in existing designs. The LUXEON IR ONYX allows for new possibilities for miniaturization of spectroscopy and hyperspectral imaging applications in hand-held devices for mobile, industrial, and medical applications.

  • Radiant Power over 40mW IR (600–1050nm) to reduce exposure time
  • More than 80 μW/nm over a broad range (750–1000nm)
  • 2.75mm x 2.00mm package with a 2 pad configuration that is compatible with the industry common footprint
  • Lumileds phosphor expertise resulting in robust, long lifetime phosphors
  • Flat spectrum allows for ease of calibration

LUXEON UV FC Line

With FlipChip platform technology, LUXEON UV FC Line contains both 1mm2 and 2mm2 die sizes and is the smallest and highest power density (W/cm2) ultraviolet with FlipChip Technology in a Chip Scale Package (CSP) LED that can be reflowed onto a substrate with standard surface mount (SMT) equipment and process. LUXEON UV FC Line LEDs enable tighter beam control and high packing density of LEDs on a chip on board solution and completely eliminate wire bonds in the system. LUXEON UV FC Line is the ideal choice for cost sensitive applications to achieve high irradiance at high current density, maximizing W/$ by taking advantage of the lowest thermal resistance of a CSP device.

  • Ultraviolet wavelength range of 380nm to 420nm for a range of options
  • Micro sized CSP: 1.0mm2 for design flexibility and packing density
  • No wire bonds allows for direct attach and reflow
  • 5-sided emitter with batwing radiation pattern
  • Low thermal resistance for leading system level W/$
  • Maximum drive current of 1A/mm2 delivers superior flux for reduced LED count

LUXEON UV U Line

At a micro package size compared to other ultraviolet and violet LEDs, LUXEON UV U Line LEDs are SMT devices that can be assembled in tight arrays with spacing of only 200 microns, which enables high power density (W/cm²) systems for superior efficiency and design freedom. These products are undomed for precise optical control and include a portfolio of 1mm² and 2mm² die sizes covering ultraviolet and violet light. The superior power density, excellent robustness of CSP technology and real world efficacy enable leading performance and efficient solution development in a wide variety of UV specialty lighting applications.

  • Offering ultraviolet in 380-400nm and violet (400–420nm) for a range of options
  • Small 2.2mm² to 3.6mm² SMT footprint enables highest W/cm² power density, design freedom
  • 1A per mm² max drive current allows more power per LED
  • Up to 50%+ efficiency reduces heat output
  • AlN package Rth as low as 1.8 K/W for better thermal management
