LUXEON IR Family

A family of infrared emitters that maximize system performance

LUXEON IR Family

The LUXEON IR Family includes a wide selection of package sizes and optical features to cover all application requirements and fields of view. It is available in multiple wavelengths and beam angles addressing a variety of applications as well as optimized radiant power and radiant intensity levels to meet application requirements. LUXEON IR Family is designed and manufactured with the same quality standards as demanded in Lumileds Automotive, Illumination and Mobile segments.


LUXEON IR 2720 Line


LUXEON IR 2720 is a line of high power infrared emitters in a reliable package design, affirming long lifetime and robustness in many types of application conditions. The LUXEON IR 2720 Line uses an industry standard footprint for ease of integration and upgrades of existing system designs.

  • Available in 850nm and 940nm wavelengths to provide optimized performance for each type of application
  • Radiant Power: 1300 mW (850nm) and 1250 mW (940nm) for a greater system performance
  • 2.75mm x 2.00mm package with a 2 pad configuration that is compatible with the industry standard footprint to enable a direct upgrade in existing designs

LUXEON IR Compact Line


The LUXEON IR Compact Line is a product line of high power infrared emitters specifically designed for high efficiency as required in a small spaces. Their compact and well-defined light source geometry allows them to be easily coupled into secondary optics for tight beam control. LUXEON IR Compact Line is designed with innovative LUXEON technology to provide industry-leading performance. Through best-in-class thermal conductivity, LUXEON IR Compact Line has excellent performance at actual operating conditions.

  • Available in 850nm and 940nm wavelengths to provide optimized performance for each type of application
  • Radiant Power: 1050mW (850nm) and 1150mW (940nm) for a greater system performance
  • Compact package of 1.9mm x 1.37mm with a 2-pad configuration provides the highest power density in the industry for a new level of miniaturization
  • Ultra-low Rth of 2.8°C/W, solves thermal challenges and supports space saving designs

LUXEON IR Domed Line


The LUXEON IR Domed Line is a product line of high power infrared emitters tailored to application needs by offering a variety of products at multiple infrared wavelengths and optical radiation patterns. LUXEON IR Domed Line is designed with innovative LUXEON technology to provide industry-leading performance. Through best-in-class thermal conductivity, LUXEON IR Domed Line has excellent performance at actual operating conditions. The LUXEON IR Domed Line uses an industry standard footprint for ease of integration and upgrading existing system designs.

  • Available in 850nm and 940nm wavelengths to provide optimized performance for each type of application
  • Radiant Power: 1350mW (850nm) and 1400mW (940nm) for a greater system performance
  • Three emission patterns: 60°, 90° and 150° to address diverse application needs, high punch, long range and high uniformity
  • 3.7mm x 3.7mm package with a 3 pad configuration that is compatible with the industry standard footprint to enable a direct upgrade in existing designs
  • Ultra-low Rth of 2.5°C/W, the industry’s best thermal conductivity, solves thermal challenges and supports space saving designs

LUXEON IR Compact Line for Automotive


The LUXEON IR Compact Line for Automotive is a product line of high power infrared emitters with Automotive qualification specifically designed for high efficiency as required in small spaces. Their compact and well-defined light source geometry allows them to be easily coupled into secondary optics for tight beam control. LUXEON IR Compact Line for Automotive is designed with innovative technology to provide industry-leading performance. Through best-in-class thermal conductivity, LUXEON IR Compact Line has excellent performance at actual operating conditions.

  • Available in 850nm and 940nm wavelengths to provide optimized performance for each type of application
  • Radiant Power: 1050mW (850nm) and 1150mW (940nm) for a greater system performance
  • Compact package of 1.9mm x 1.37mm with a 2-pad configuration provides the highest power density in the industry for a new level of miniaturization
  • Ultra-low Rth of 3.5°C/W, solves thermal challenges and supports space saving designs.

LUXEON IR Domed Line for Automotive


The LUXEON IR Domed Line for Automotive is a product line of high power infrared emitters with Automotive qualification tailored to application needs by offering a variety of products at multiple infrared wavelengths and optical radiation patterns. LUXEON IR Domed Line is designed with innovative LUXEON technology to provide industry-leading performance. Through best-in-class thermal conductivity, LUXEON IR Domed Line has excellent performance at actual operating conditions. The LUXEON IR Domed Line uses an industry standard footprint for ease of integration and upgrading existing system designs.

  • Available in 850nm and 940nm wavelengths to provide optimized performance for each type of application
  • Radiant Power: 1350mW (850nm) and 1400mW (940nm) for a greater system performance
  • Four emission patterns: 50°, 60°, 90° and 150° to address diverse application needs, high punch, long range and high uniformity
  • 3.7mm x 3.7mm package with a 3 pad configuration that is compatible with the industry standard footprint to enable a direct upgrade in existing designs
  • Ultra-low Rth of 2.5°C/W, the industry’s best thermal conductivity, solves thermal challenges and supports space saving designs

LUXEON IR ONYX


The LUXEON IR ONYX emitter features a continuous broadband infrared (IR) emission from 650 to 1100nm with superior light output characteristics. The product comes in an industry standard 2720 package and footprint for easy integration in existing designs. The LUXEON IR ONYX allows for new possibilities for miniaturization of spectroscopy and hyperspectral imaging applications in hand-held devices for mobile, industrial, and medical applications.

  • Radiant Power over 40mW IR (600–1050nm) to reduce exposure time
  • More than 80 μW/nm over a broad range (750–1000nm)
  • 2.75mm x 2.00mm package with a 2 pad configuration that is compatible with the industry common footprint
  • Lumileds phosphor expertise resulting in robust, long lifetime phosphors
  • Flat spectrum allows for ease of calibration
