LUXEON IR Family for Automotive

The LUXEON IR Family for Automotive is a family of high power infrared emitters tailored to applications needs by offering a variety of products at mulitple infrared wavelengths and optical radiation patterns. All LUXEON IR LEDs for Automotive are AEC – Q102 qualified.

Read the press release for more information >

Don’t miss a thing

Sign up and be the first to be notified when the LUXEON IR Family for Automotive launches and receive the datasheet:

LUXEON IR Compact for Automotive

The LUXEON IR Compact Line for Automotive is a product line of high power infrared emitters with Automotive qualification specifically designed for high efficiency as required in small spaces. Their compact and well-defined light source geometry allows them to be easily coupled into secondary optics for tight beam control. LUXEON IR Compact Line for Automotive is designed with innovative technology to provide industry-leading performance. Through best-in-class thermal conductivity, LUXEON IR Compact Line has excellent performance at actual operating conditions.

  • Available in 850nm and 940nm wavelengths to provide optimized performance for each type of application
  • Radiant Power: 1050mW (850nm) and 1150mW (940nm) for a greater system performance
  • Compact package of 1.9mm x 1.37mm with a 2-pad configuration provides the highest power density in the industry for a new level of miniaturization
  • Ultra-low Rth of 3.5°C/W, solves thermal challenges and supports space saving designs.

LUXEON IR Domed for Automotive Line

LUXEON IR Domed for Automotive Line are high power infrared emitters tailored to application needs by offering a variety of products at multiple infrared wavelengths and optical radiation patterns. Through best-inclass thermal conductivity, LUXEON IR Domed for Automotive Line has excellent performance at actual operating conditions. Its industry standard footprint allows ease of integration and upgrading existing system designs. All LUXEON IR Domed for Automotive Line emitters are AEC-Q102 and USCAR33 qualified and are designed with innovative LUXEON technology to provide industry leading performance.

  • Available in 850nm and 940nm wavelengths to provide optimized performance for each type of application
  • Radiant Power of 1350mW (850nm) and 1450mW (940nm) for greater system performance
  • Four emission patterns of 50°, 60°, 90° and 150° to address diverse application needs, high punch, long range and high uniformity
  • 3.7mm x 3.7mm package with 3 pad configuration is compatible with the industry standard footprint, enabling a direct upgrade in existing designs
  • Ultra-low Rth of 2-3.1°C/W, the industry’s best thermal conductivity, solves thermal challenges and supports space saving designs
