LUXEON SunPlus Series

LEDs engineered to deliver the precise wavelengths of light needed to improve crop yield

LUXEON SunPlus Series for Horticulture

The LUXEON SunPlus Series is purpose-built to enable ease of system design for Horticulture applications. The LUXEON SunPlus Series offers the only LEDs available today that are binned and tested based on Photosynthetic Photon Flux (PPF). The LUXEON SunPlus Series includes two different packages: LUXEON SunPlus 20 Line, which is 2.0mm x 2.0mm and LUXEON SunPlus 35 Line, which is 3.5mm x 3.5mm. The LUXEON SunPlus Series includes options for single driver solutions and multi-channel, color tunable solutions.

For more information, check out the Lumileds Horticulture Website and the Horticulture Lighting Calculator.

Product performance of LUXEON SunPlus Series at test conditions.

ProductColorPeak
Wavelength (nm)
PPF (​μmol/s) in PAR (400 to 700nm)PPF/W Typical (µmol/J)Part Number
MinimumMaximumMinimumTypical
LUXEON SunPlus 20 Line Far Red 720 750 1.10 1.37 2.26 L1SP-FRD0002000000
Deep Red 655 670 1.60 1.81 2.65 L1SP-DRD0002000000
Royal Blue 445 455 1.90 2.04 2.11 L1SP-RYL0002000000
Lime - - 1.50 1.59 1.66 L1SP-LME0002000000
Cool White - - 1.40 1.51 1.57 L1SP-CW90002000000
LUXEON SunPlus 35 Line Purple (2.5% Blue) - - 0.45 0.51 1.80 L1SP-PRP0003500000
Purple (12.5% Blue) - - 0.50 0.58 2.02 L1SP-PRP1003500000
Purple (25% Blue) - - 0.55 0.63 2.24 L1SP-PRP2003500000
Far Red 720 740 0.30 0.32 1.83 L1SP-FRD00035R0000
Deep Red 650 670 0.45 0.47 2.23 L1SP-DRD00035R0000
Royal Blue 440 455 0.55 0.61 2.00 L1SP-RYL0003500000
Lime - - 0.60 0.65 2.13 L1SP-LME0003500000



Documentation

Design Resources

  • Mechanical
  • Optical

Features and Benefits

  • 120° and 150° viewing angle of choice for various design needs
  • 2.0mm x 2.0mm package footprint

Applications

  • Horticulture
