LUXEON SunPlus 2835 Line

This line of purpose-built LEDs for horticulture enables growers to maximize their crop yields. Designed specifically for interweaving or vertical farming applications, LUXEON SunPlus 2835 Line LEDs deliver perfect uniformity at short distances and are offered in a variety of individual colors so users can design their own spectra—as well as ready-made color points already designed to maximize yields. The LUXEON SunPlus 2835 Line includes options for single driver solutions and multi-channel, color tunable solutions.

For more information, check out the Lumileds Horticulture Website and the Horticulture Lighting Calculator.

Features & Benefits

  • 120° angle for uniform light distribution for greenhouse, vertical farming and interweaving applications
  • 2.8 x 3.5mm package
Expand Media

Applications

  • Horticulture
Expand Applications

Please read these terms and conditions carefully.

LUMILEDS shall not be liable for any kind of loss of data or any other damages, direct, indirect or consequential, resulting from the use of the provided information and data. Although LUMILEDS has attempted to provide the most accurate information and data, the materials and services information and data are provided “as is” and LUMILEDS neither warranties, nor guarantees the contents and correctness of the provided information and data. LUMILEDS reserves the right to make changes without notice. You as user agree to this disclaimer and user agreement with the download or use of the provided materials, information and data.

I agree I do not agree

Product performance of LUXEON SunPlus 2835 Line at 120mA, Tj=25°C.

Color Peak
Wavelength (nm)
PPF (​μmol/s) in PAR (400 to 700nm) PPF/W Typical (µmol/J) Part Number
Minimum Maximum Minimum Typical
Horticulture White 0.71 0.78 2.28 L1SP-PNK1002800000
Purple (2.5% Blue) 0.58 0.63 1.84 L1SP-PRP0002800000
Purple (12.5% Blue) 0.64 0.70 2.04 L1SP-PRP1002800000
Purple (25% Blue) 0.67 0.74 2.16 L1SP-PRP2002800000
Far Red 720 740 0.54 0.60 2.32 L1SP-FRD0002800000
Deep Red 650 670 0.56 0.62 2.32 L1SP-DRD0002800000
Royal Blue 440 455 0.67 0.74 2.06 L1SP-RYL0002800000
Lime 0.72 0.80 2.22 L1SP-LME0002800000
