Outstanding light performance

Halogen headlights designed to give you superior light performance and driving comfort, whatever the conditions.

OEM halogen bulbs the world trusts

Lumileds is the world’s leading automotive lighting manufacturer. We’re renowned for technological innovation, high quality materials and best-in-class products.

It’s our commitment to providing the very highest standards that makes Lumileds the preferred partner of the world’s largest car manufacturers.

Our 12V and 24V lighting range is a family of lighting solutions, designed for the needs of all B2B costumers:

  • Standard - Highly reliable lamp that’s resistant to damaging vibrations.
  • BlueVision - Crisp white light for a stylish look, color matching with LED e.g. DRL.
  • LongerLife (LL, HP LL) - Bulbs that maximize lifetime and minimize maintenance.

Discover our innovative halogen range

Get superior light performance that makes drivers safer and more stylish on the road.

H18: The one-filament halogen light

Enabling ultra-compact and stylish headlight designs

Modern LED technology is allowing headlights to become narrower and rectangular shaped, making them more compact and stylish. Traditional halogen lighting needs to adapt to this design trend.

Carmakers are looking for solutions that retain the traditional cost-efficient halogen lights, while meeting these new design standards. While existing lamps do not allow for further size reduction, our high-flux halogen lights meet this challenge.

  • Ultra-narrow reflector to fit modern compact headlight design
  • Improved beam performance for a safer, more comfortable drive
  • Compact metal socket so it’s easy to fit in a wide range of models
  • High filament accuracy directing light just where it’s needed

View leaflet

H19: Compact halogen headlamp designs

Raising the bar for stylish compact headlamp design

It’s now possible to get the slim look of LED headlamps with high-quality halogen lights. Our innovative H19 allow for a very compact and narrow reflector headlight design. With these halogen-based versions, you can rapidly design headlight systems that are as compact and stylish as high-end LEDs, without compromising on optical performance.

This high-flux halogen light source, with tight tolerances, lets you design new headlamps with enhanced luminous flux for compact cars in the A/B segment.

  • Tight optical and mechanical tolerances
  • Symmetric shield and coil design
  • 20% higher luminance compared to H4

Halogen Product Overview

12 V Car Lighting + Two-Wheeler

 H4 STDH4 LLH4 HPLLH4 HP+H4 BV+H4 ED
type Nr. 12342 STD 12342 LL 12342 HPLL 12342 HP+ 12342 BV+ 12342 ED
Voltage 12.0 V 13.2 V 13.2 V 13.2 V 13.2 V 13.2 V
Power 60/55 W 60/55 W 60/55 W 60/55 W 60/55 W 60/55 W
Lumen output 1650/1000 lm 1650/1000 lm 1650/1000 lm 1750/1100 lm 1650/1000 lm 1650/1000 lm
Lifetime B3 350 h 900 h 2000 h 400 h 200 h

350 h

Lifetime Tc 700 h 1500 h 3000 h 700 h 400 h 700 h
Regulations R37 R37 R37 R37 R37 R37
DOT no no no no no no



12 V Car Lighting + Two-Wheeler

 H7 STDH7 LLH7 HPLLH7 BV+H8 LLH8 BV+
type Nr. 12972 STD 12972 LL 12972 HPLL 12972 BV+ 12360 LL 12360 BV+
Voltage 13.2 V 13.2 V 13.2 V 13.2 V 13.2 V 13.2 V
Power 55 W 55 W 55 W 55 W 35 W 35 W
Lumen output 1500 lm 1500 lm 1500 lm 1500 lm 800 lm 800 lm
Lifetime B3 330 h 700 h 1000 STD 200 h 800 h 200 h
Lifetime Tc 550 h 1100 h 1500 STD 350 h 1500 h 400 h
Regulations R37 R37 R37 R37 R37 R37
DOT yes yes yes yes yes no

 *This overview represents just an excerpt of our complete automotive headlamp portfolio

12 V Car Lighting + Two-Wheeler

 H9 STDH9 BV+H11 LLH11 BV+H17 EDH18 STD
type Nr. 12361 STD 12361 BV+ 12362 LL 12362 BV+ 12642 ED 12643 STD
Voltage

13.2 V

13.2 V 13.2 V 13.2 V 13.2 V 13.2 V
Power 65 W 65 W 55 W 55 W 35/35 W 65 W
Lumen output 2100 lm 2100 lm 1350 lm 1350 lm 900/600 lm 1700 lm
Lifetime B3 270 h 200 h 1000 h 200 h 100 h 330 h
Lifetime Tc 540 h 400 h 2000 h 350 h 200 h 550 h
Regulations R37 R37 R37 R37 R37 R37
DOT yes no yes no no yes



12 V Car Lighting + Two-Wheeler

 H18 LLH18 HPLLH19 LLHIR 2 STDHIR 2 LLHS1 LLHS1 ED
type Nr. 12623 LL 12643 HPLL 12644 LL 9012 STD 9012 LL 12636 LL 12636 ED
Voltage 13.2 V 13.2 V 13.2 V 13.2 V 13.2 V 13.2 V 13.2 V
Power 65 W 65 W 60/55 W 55 W 55 W 35/35 W 35/35 W
Lumen output 1700 lm 1700 lm 1750/1200 lm 1875 lm 1875 lm 825/525 lm 825/525 lm
Lifetime B3 700 h 1000 h 900 h 500 h 900 h 100 h 100 h
Lifetime Tc 1100 h 2000 h 1500 h 900 h 1400 h 200 h 200 h
Regulations R37 R37 R37 R37 R37 R37 R37
DOT yes yes yes yes yes no no



24 V Bus & Truck Lighting

 H1 MLH3 MLH4 MLH7 MLH11 ML
type Nr. 13258 ML 13336 ML 13342 ML 13972 ML 24362 ML
Voltage 24 V 24 V 24 V 24 V 24 V
Power 70 W 70 W 75/70 W 70 W 70 W
Lumen output 1900 lm 1750 lm 1900/1135 lm 1750 lm 1600 lm
Lifetime B3 500 h 500 h 900 h 700 h 850 h
Lifetime Tc 1000 h 1200 h 1800 h 1200 h 1500 h
Regulations R37 R37 R37 R37 R37
DOT no no no no no
