LED Cell Phone Flash and Flash Modules

Whether your device is for a camera aficionado or you simply want a functional Flash LED, Lumileds has a product that can fit your requirements and budget.  Lumileds pioneering technical innovations have produced the world’s first color tunable product, high CRI Flash LED, and mid-power Flash LED as well as set the industry standard in tight color range, off-state-white, color-over-source, and Vf, to name a few.   LUXEON Flash LEDs are used by every major smartphone OEM at all price points, as a testament to Lumileds R&D innovation, vertically integrated supply chain, and competitive.

For the best possible images in a digital imaging platform, LUXEON Flash is the clear choice.

To learn more about adding LUXEON Flash to your digital imaging device please contact us


  • LUXEON Flash 4
    PartTyp Flux (lm)Typ Vf (V)Typ CCT (K)Off-State AppearanceTest Current (mA)
    LXCL-PWF4 180 3.2 5800 Yellow 1000
  • LUXEON Flash 5
    PartTyp Flux (lm)Typ Vf (V)Typ CCT (K)Off-State AppearanceTest Current (mA)
    LXCL-EL05 240 3.2 5500 White 1000
  • LUXEON Flash 6
    Part Typ Flux (lm)Typ Vf (V)Typ CCT (K)Off-State AppearanceTest Current (mA)
    LXCL-EW06 220 3.2 5500 White 1000
  • LUXEON Flash 7
    PartTyp Flux (lm)Typ Vf (V)Typ CCT (K)Off-State AppearanceTest Current (mA)
    LXCL-EY17 260 3.2 6000 White 1000
    LXCL-LW07 500 3.25 4500 White 2000


A Broad Portfolio of Flash Solutions

  • High flux rear-facing camera flash LEDs
  • Tunable flash LED solutions for front and rear camera providing optimal color representation
  • High CRI solutions with superior color rendering for front and rear cameras
  • Mid-power LUXEON Flash LEDs for feature phones and front-facing cameras
  • Complimentary customer-focused technical support (optical, mechanical, electrical, thermal)
